Applications
Multi-purpose Outdoor - Aerial Lashed, Duct, Direct Buried

Constructions
Dielectric, Armored, Double Armored

Fiber Count
2 to 432 fibers in Color-coded Buffer Tubes

Fiber Types
Singlemode / Multimode

Options
Gel-Filled Core / Steel Central Member / Copper Pair(s)

Other versions
Central / Heavy Duty / Indoor-Outdoor

Performance
ANSI/ICEA, IEC, RUS, Telcordia GR-20

Mechanical Specifications
Installation
[+] Maximum installation load 600 lbf (2670 N)
[+] Maximum operation load 180 lbf (800 N)
Temperature Range
[+] Shipping and Storage -40 ºF to +167 ºF (-40 ºC to +75 ºC)
[+] Installation -22 ºF to +140 ºF (-30 ºC to +60 ºC)
[+] Operation -40 ºF to +158 ºF (-40 ºC to +70 ºC)

*Cables with fiber counts greater than 288 contain 24 fibers in a larger PBT buffer tube with 12 fiber binder groups. Rated buffer storage length is 8 feet (2.4 meters)

N/A 5

N/A 0.5

N/A 13.8

N/A 118

N/A 175

N/A 11

N/A 28

N/A 8

N/A 21

LT-DJA-2

N/A 62 to 72

N/A 6

N/A 0.6

N/A 14.5

N/A 138

N/A 205

N/A 11

N/A 29

N/A 9

N/A 22

LT-DJA-3

N/A 74 to 84

N/A 7

N/A 0.6

N/A 15.5

N/A 153

N/A 228

N/A 12

N/A 31

N/A 9

N/A 23

LT-DJA-4

N/A 86 to 96

N/A 8

N/A 0.7

N/A 16.6

N/A 170

N/A 253

N/A 13

N/A 33

N/A 10

N/A 25

LT-DJA-5

N/A 98 to 108

N/A 9

N/A 0.7

N/A 17.3

N/A 182

N/A 272

N/A 14

N/A 35

N/A 10

N/A 26

LT-DJA-6

N/A 110 to 120

N/A 10

N/A 0.7

N/A 18.3

N/A 201

N/A 300

N/A 14

N/A 37

N/A 11

N/A 28

LT-DJA-7

N/A 122 to 132

N/A 11

N/A 0.80

N/A 19.1

N/A 212

N/A 315

N/A 15

N/A 38

N/A 11

N/A 29

LT-DJA-8

N/A 134 to 216

N/A 18

N/A 0.80

N/A 20.1

N/A 239

N/A 356

N/A 16

N/A 40

N/A 12

N/A 30

LT-DJA-9

N/A 218 to 264

N/A 22

N/A 0.9

N/A 22.1

N/A 283

N/A 421

N/A 17

N/A 44

N/A 13

N/A 33

LT-DJA-10

N/A 266 to 288

N/A 24

N/A 0.9

N/A 22.9

N/A 295

N/A 439

N/A 18

N/A 46

N/A 14

N/A 34

LT-DJA-11

N/A 290 to 432*

N/A 18

N/A 0.9

N/A 22.1

N/A 279

N/A 415

N/A 17

N/A 44

N/A 13

N/A 33

Contact

Item #

Fiber
Count

Number
of
Buffer
Tubes

Diameter
(in)

Diameter
(mm)

Approximate
Cable
Weight
lb/MFT

Approximate
Cable
Weight
kg/km

Bend
Radius
Load
(in)

Bend
Radius
Load
(cm)

Bend
Radius
No Load
(in)

Bend
Radius
No Load
(cm)

Item #	Fiber Count	Number of Buffer Tubes	Diameter (in)	Diameter (mm)	Approximate Cable Weight lb/MFT	Approximate Cable Weight kg/km	Bend Radius Load (in)	Bend Radius Load (cm)	Bend Radius No Load (in)	Bend Radius No Load (cm)

LT-DJA-1	N/A 2 to 60	N/A 5	N/A 0.5	N/A 13.8	N/A 118	N/A 175	N/A 11	N/A 28	N/A 8	N/A 21
LT-DJA-2	N/A 62 to 72	N/A 6	N/A 0.6	N/A 14.5	N/A 138	N/A 205	N/A 11	N/A 29	N/A 9	N/A 22
LT-DJA-3	N/A 74 to 84	N/A 7	N/A 0.6	N/A 15.5	N/A 153	N/A 228	N/A 12	N/A 31	N/A 9	N/A 23
LT-DJA-4	N/A 86 to 96	N/A 8	N/A 0.7	N/A 16.6	N/A 170	N/A 253	N/A 13	N/A 33	N/A 10	N/A 25
LT-DJA-5	N/A 98 to 108	N/A 9	N/A 0.7	N/A 17.3	N/A 182	N/A 272	N/A 14	N/A 35	N/A 10	N/A 26
LT-DJA-6	N/A 110 to 120	N/A 10	N/A 0.7	N/A 18.3	N/A 201	N/A 300	N/A 14	N/A 37	N/A 11	N/A 28
LT-DJA-7	N/A 122 to 132	N/A 11	N/A 0.80	N/A 19.1	N/A 212	N/A 315	N/A 15	N/A 38	N/A 11	N/A 29
LT-DJA-8	N/A 134 to 216	N/A 18	N/A 0.80	N/A 20.1	N/A 239	N/A 356	N/A 16	N/A 40	N/A 12	N/A 30
LT-DJA-9	N/A 218 to 264	N/A 22	N/A 0.9	N/A 22.1	N/A 283	N/A 421	N/A 17	N/A 44	N/A 13	N/A 33
LT-DJA-10	N/A 266 to 288	N/A 24	N/A 0.9	N/A 22.9	N/A 295	N/A 439	N/A 18	N/A 46	N/A 14	N/A 34
LT-DJA-11	N/A 290 to 432*	N/A 18	N/A 0.9	N/A 22.1	N/A 279	N/A 415	N/A 17	N/A 44	N/A 13	N/A 33
