Applications
Multi-purpose Outdoor - Aerial Lashed, Duct, Direct Buried

Constructions
Dielectric, Armored, Double Armored

Fiber Count
2 to 432 fibers in Color-coded Buffer Tubes

Fiber Types
Single-mode / Multi-mode

Options
Gel-Filled Core / Steel Central Member / Copper Pair(s)

Other versions
Central / Heavy Duty / Indoor-Outdoor

Performance
ANSI/ICEA, IEC, RUS, Telcordia GR-20

Mechanical Specifications
Installation
[+] Maximum installation load 600 lbf (2670 N)
[+] Maximum operation load 180 lbf (800 N)
Temperature Range
[+] Shipping and Storage -40 ºF to +167 ºF (-40 ºC to +75 ºC)
[+] Installation -22 ºF to +140 ºF (-30 ºC to +60 ºC)
[+] Operation -40 ºF to +158 ºF (-40 ºC to +70 ºC)

*Cables with fiber counts greater than 288 contain 24 fibers in a larger PBT buffer tube with 12 fiber binder groups. Rated buffer storage length is 8 feet (2.4 meters)

N/A 5

N/A 0.67

N/A 17.1

N/A 205

N/A 306

N/A 13

N/A 34

N/A 10

N/A 26

LT-DJDA-2

N/A 62 to 72

N/A 6

N/A 0.7

N/A 17.8

N/A 232

N/A 346

N/A 14

N/A 36

N/A 11

N/A 27

LT-DJDA-3

N/A 74 to 84

N/A 7

N/A 0.74

N/A 18.8

N/A 253

N/A 377

N/A 15

N/A 38

N/A 11

N/A 28

LT-DJDA-4

N/A 86 to 96

N/A 8

N/A 0.78

N/A 19.9

N/A 274

N/A 408

N/A 16

N/A 40

N/A 12

N/A 30

LT-DJDA-5

N/A 98 to 108

N/A 9

N/A 0.810

N/A 20.6

N/A 288

N/A 428

N/A 16

N/A 41

N/A 12

N/A 31

LT-DJDA-6

N/A 110 to 120

N/A 10

N/A 0.85

N/A 21.6

N/A 315

N/A 468

N/A 17

N/A 43

N/A 13

N/A 32

LT-DJDA-7

N/A 122 to 132

N/A 11

N/A 0.88

N/A 22.4

N/A 330

N/A 492

N/A 18

N/A 45

N/A 13

N/A 34

LT-DJDA-8

N/A 134 to 216

N/A 18

N/A 0.92

N/A 23.4

N/A 359

N/A 535

N/A 18

N/A 47

N/A 14

N/A 35

LT-DJDA-9

N/A 218 to 264

N/A 22

N/A 1.00

N/A 25.5

N/A 414

N/A 616

N/A 20

N/A 50

N/A 15

N/A 38

LT-DJDA-10

N/A 266 to 288

N/A 24

N/A 1.03

N/A 26.2

N/A 429

N/A 638

N/A 21

N/A 52

N/A 15

N/A 39

LT-DJDA-11

N/A 290 to 432*

N/A 18

N/A 1.01

N/A 25.7

N/A 416

N/A 619

N/A 20

N/A 51

N/A 15

N/A 38

Contact

Item #

Fiber
Count

Number
of
Buffer
Tubes

Diameter
(in)

Diameter
(mm)

Approximate
Cable
Weight
lb/MFT

Approximate
Cable
Weight
kg/km

Bend
Radius
Load
(in)

Bend
Radius
Load
(cm)

Bend
Radius
No Load
(in)

Bend
Radius
No Load
(cm)

Item #	Fiber Count	Number of Buffer Tubes	Diameter (in)	Diameter (mm)	Approximate Cable Weight lb/MFT	Approximate Cable Weight kg/km	Bend Radius Load (in)	Bend Radius Load (cm)	Bend Radius No Load (in)	Bend Radius No Load (cm)

LT-DJDA-1	N/A 2 to 60	N/A 5	N/A 0.67	N/A 17.1	N/A 205	N/A 306	N/A 13	N/A 34	N/A 10	N/A 26
LT-DJDA-2	N/A 62 to 72	N/A 6	N/A 0.7	N/A 17.8	N/A 232	N/A 346	N/A 14	N/A 36	N/A 11	N/A 27
LT-DJDA-3	N/A 74 to 84	N/A 7	N/A 0.74	N/A 18.8	N/A 253	N/A 377	N/A 15	N/A 38	N/A 11	N/A 28
LT-DJDA-4	N/A 86 to 96	N/A 8	N/A 0.78	N/A 19.9	N/A 274	N/A 408	N/A 16	N/A 40	N/A 12	N/A 30
LT-DJDA-5	N/A 98 to 108	N/A 9	N/A 0.810	N/A 20.6	N/A 288	N/A 428	N/A 16	N/A 41	N/A 12	N/A 31
LT-DJDA-6	N/A 110 to 120	N/A 10	N/A 0.85	N/A 21.6	N/A 315	N/A 468	N/A 17	N/A 43	N/A 13	N/A 32
LT-DJDA-7	N/A 122 to 132	N/A 11	N/A 0.88	N/A 22.4	N/A 330	N/A 492	N/A 18	N/A 45	N/A 13	N/A 34
LT-DJDA-8	N/A 134 to 216	N/A 18	N/A 0.92	N/A 23.4	N/A 359	N/A 535	N/A 18	N/A 47	N/A 14	N/A 35
LT-DJDA-9	N/A 218 to 264	N/A 22	N/A 1.00	N/A 25.5	N/A 414	N/A 616	N/A 20	N/A 50	N/A 15	N/A 38
LT-DJDA-10	N/A 266 to 288	N/A 24	N/A 1.03	N/A 26.2	N/A 429	N/A 638	N/A 21	N/A 52	N/A 15	N/A 39
LT-DJDA-11	N/A 290 to 432*	N/A 18	N/A 1.01	N/A 25.7	N/A 416	N/A 619	N/A 20	N/A 51	N/A 15	N/A 38
